Design / Henning Larsen Architects
The Plaza Point Drainage Grate with fixed frame is made of SG iron with a heavy wall thickness, ensuring high durability and a long service life. The design makes the frame appear visually integrated into the grate, creating a harmonious expression in the paving.
The point drainage grate is compatible with standard 315 mm chambers, where it is installed with a gasket, as well as 280 mm wells without a gasket.
The grate is available as:
> Flat surface
> Concave / Radius
> V-shape
> Closed
> Flat surface / for floating frame (asphalt)
The untreated cast iron makes the grate suitable for even the most demanding environments, both in coastal and urban areas. With a load class of 40 tonnes and child safety features, the Plaza point drainage grate is a solid and secure solution for efficient drainage.
Item number
No SKU available
Material
Untreated cast iron
Dimension
W 300 x L 300 mm / Ø277
Assembly
Download installation instructions
Weight
48kg.
Additional information
The load class is 40 tonnes. Load class E/F - i.e. heavy traffic.
The Plaza Point Drainage Grate with fixed frame is made of SG iron with a heavy wall thickness, ensuring high durability and a long service life. The design makes the frame appear visually integrated into the grate, creating a harmonious expression in the paving.
The point drainage grate is compatible with standard 315 mm chambers, where it is installed with a gasket, as well as 280 mm wells without a gasket.
The grate is available as:
> Flat surface
> Concave / Radius
> V-shape
> Closed
> Flat surface / for floating frame (asphalt)
The untreated cast iron makes the grate suitable for even the most demanding environments, both in coastal and urban areas. With a load class of 40 tonnes and child safety features, the Plaza point drainage grate is a solid and secure solution for efficient drainage.
Henning Larsen Architects
Henning Larsen was one of Denmark's most renowned architects, known for combining aesthetics, function and light. His influence on modern architecture continues to inspire architects around the world.
